Indoor/outdoor tennis Lighting solutions

Designs to meet all recommended lux levels for grass, clay, carpet and hard courts

INDOOR Lux LevelsOutdoor Lux levels

TENNIS Lighting

Samuel Groth holds the record for the world's fastest serve at 163.7mph. With speeds like this, umpires and spectators need adequate lighting to view fast paced rallies.

Whether it be an indoor multi-court training facility for a sports academy, or a regional tennis club, Kellwood Lighting can design and install a solution to ensure that nothing is missed on centre court.

Proven Benefits

Kellwood's tennis court lighting design consultants always aim to represent the most competitive high-end option and will endeavour to find the best possible product for your requirements.

Discuss your tennis court lighting project

LUX Levels for Indoor Tennis Courts

ApplicationTypical UseHorizontal
Illuminance
RaGlareNotes
Eave (LUX)Emin/Eave
Class 1International7500.7>60<50-
Class 2Regional5000.7>60<50-
Class 3Club3000.5>20<50-

IMPORTANT NOTE: data is compiled from indoor-tennis-specific lighting publications. However, these are recommendations only; careful consideration must go into every unique environment.

Popular Features and Accessories

Smart Controls

Wire Guards

Mounting Types

Emergency Options

Low Glare

CONTACT KELLWOOD TO DISCUSS YOUR indoor TenniS LIGHTING PROJECT

Class 1 (National) - 4 Row Surface Mounted Solution

  • Mount height 9m
  • 22No. Lights per row
  • 90W Drummond 3 Series
  • 60°/90° Optics
  • Eav = 700
  • Uo = 0.94

Class 2 (Regional) - 4 Row Surface Mounted Solution

  • Mount height 9m
  • 22No. Lights per row
  • 60W Drummond 3 Series
  • 60°/90° Optics
  • Eav = 450
  • Uo = 0.95

Class 3 (Local) - 4 Row Surface Mounted Solution

  • Mount height 9m
  • 22No. Lights per row
  • 30W Drummond 3 Series
  • 60°/90° Optics
  • Eav = 250
  • Uo = 0.94

LUX Levels for Outdoor Tennis Courts

ApplicationTypical UseHorizontal
Illuminance
RaGlareNotes
Eave (LUX)Emin/Eave
Class 1International5000.7>80<50-
Class 2Regional3000.7>60<50-
Class 3Recreational2000.6>20<55-

IMPORTANT NOTE: data is compiled from outdoor-tennis-specific lighting publications. However, these are recommendations only; careful consideration must go into every unique environment.

Popular Features and Accessories

Forward Throw Optics

Marine Grade Finish

Smart Controls

Mounting Types

IMPORTANT NOTE: data is compiled from outdoor-tennis-specific lighting publications. However, these are recommendations only; careful consideration must go into every unique environment.

CONTACT KELLWOOD TO DISCUSS YOUR tennis court LIGHTING PROJECT

Class 1 (National) - 6 Pole Solution

  • 10m Poles
  • 3No. Lights per pole
  • 920W Ayrton 3 Series
  • IESNA Type IV Optic with Short Lateral Throw
  • Eav = 750
  • Uo = 0.70
  • Tilt = 0°

Class 2 (Regional) - 6 Pole Solution

  • 10m Poles
  • 2No./3No. Lights per pole
  • 770W Ayrton 3 Series
  • IESNA Type IV Optic with Short Lateral Throw
  • Eav = 550
  • Uo = 0.71
  • Tilt = 0°

Class 3 (Local) - 6 Pole Solution

  • 10m Poles
  • 2No. Lights per pole
  • 610W Ayrton 3 Series
  • IESNA Type IV Optic with Short Lateral Throw
  • Eav = 300
  • Uo = 0.73
  • Tilt = 0°
